ENGINE
146
03 BRACKET
04 ASSY.OIL SEPARATOR
05 HOSE(FROMBREATHER
TOOIL SEPERATOR)
06 ASSY.BLOWBY (AIR
INTAKE CIRCUIT)
08 ASSYOIL RETURN LINE
(BLOWBY)
09 ASSY BRACKET (BLOW
BYTOAIR INTAKE)
10 ASSY BRACKET (OIL
RETURNLINE)
12 CLAMP (BLOW-BY
RETURNLINE)
11 HOSE CLIP
13 HEXSCREW
BLOW BY RECIRCULATION CIRCUIT
TATA SAFARI DICOR ENGINE EURO-III / BS-III
SR.
NO.
Description
EXPLODED VIEWS
