BODY

47

9.2.26 REAR SEAT BELT

REMOVAL

1. Remove parcel shelf.

2. Remove rear seat backrest (for removal

process refer rear seat removal process).

3. Flip the cushion assembly.

4. Remove rear seat belt bottom mounting

fastener.

5. Remove the C pillar upper and lower trim. (For

procedure refer C pillar removal process.)

6. Remove two upper mounting bolts on C piller

BIW panel.
