TIAGO

BODY



FOR EMERGENCY LOCKING RETRACTOR

REMOVAL (ELR)

1. Fold the front seat to have easy access for the

belt removal.

2. Loosen and remove the lower mounting bolt of

seat belt.

3. Remove front seat belt anchor mounting bolt.

4. Remove lower “B” pillar trim. (For procedure

refer “B” pillar trim removal procedure in Body

section.)

5. Loosen and remove the ELR mounting bolt.

6. Remove the front seat belt assembly.

FITMENT

For fitment follow reverse procedure of removal.
