1.2L REVOTRON ENGINE
45
Engine Suspension
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Hex FL Nut AM12X1.5 For Mount
11
2 H/FL BOLT M8X28 TS17130 10.9SS8451S2-YH
3.2
3 B Mount Assembly
4 Nyloc Nut M8
5 FL Bolt M10X1.25x50 For Mount Bracket
5.8
6 B-Mount Bracket
7 SCR M10X1.25X30 At Bottom Of Bracket
8 H/FL Bolt M10X40 For Transaxle Side B-Mount
4.2
9 Stud For-B-Mount
10 B-Mount-Transaxle-Side
11 C-Mount
12 H/FL Bolt M10X80 C-Mount-Link-Mount
5.4
13 H/FL Bolt M10X75 At Sleeve-C-Mount
5.4
14 C-Mount-Link-Mount
15 C-Mount-Brkt-BIW
16 Hex FL SCR M10X18 at C-Mount-Brkt-BIW
4.0
17 Bright Washer
18 Nyloc Nut M10 At Sleeve-C-Mount
19 Nyloc Nut M10 At C-Mount-Link-Mount
20 Hex FL SCR M10X25 for C-Mount
5.4
21 A-Mount Bracket-BIW
22
SCR M10X1.25X30 At Bottom Of A-Mount
Bracket-BIW
5.8
23 A Mount
24
SCR M10X1.25X30 At Top Of A-Mount Bracket-
BIW
5.8
