1.2L REVOTRON ENGINE
40
Air Intake System :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Air Filter Housing Assembly
2 ETC to Intake Manifold (Hex.Nut AM6) (4 Qty)
1.0
3 ETC to Intake Manifold (STUD CM6X45) (4 Qty)
4 Blow by hose
5 Electronic Throttle Control
6 Self-Locking Nut (Clinch Nut M8 X 1.25) (4 Qty)
2.0+0.3
7 Intake Manifold
8 Snorkel
9
H/FL Screw M6X14 FOR Snorkel Bracket (1
Qty)
1.0
10 Snorkel Bracket
11 H/FL Bolt M8X28 (2Qty)
