1.2L REVOTRON ENGINE
38
Lubrication Pump and Lines :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Oil Pump Assy Complete
2
Hex FL Bolt M8X55 for Oil Pump Assy
(6 Qty)
2.5
3 Oil Seal (Crankshaft) (Front)
4 Oil Pump
5 Hex FL Bolt M6X28 (13 Qty)
1.0
6 O-Ring (For Strainer assy)
7 Flanged Clinch Nut M6 (2 Qty)
1.0
8 Strainer Assembly (For Oil Pump)
9 Gasket (For Filter)
10 HEX FL BOLT M8X22 (For Filter) (3 Qty)
2.5
11 Adaptor (For Oil Filter Mounting)
12 Oil Filter Assembly
¾
th
Turn
13 Oil Pressure Switch
3+1
