1.2L REVOTRON ENGINE
144
ECU Pin Details
C355A - FRT WH SIDE CONNECTOR
C355B - EMS WH SIDE CONNECTOR
Pin No.
Description
Pin No.
Description
C355A-3
Sensor Gnd
C355B-1
VRS-
C355A-4
AC Pressure Gnd
C355B-2
Lambda Sig Downstream
C355A-5
Acc Pedal Pot 1 Gnd
C355B-3
Throttle Pos Sig 1
C355A-6
Acc Pedal Pot 2 Gnd
C355B-4
Heater Upstream
C355B-9
Starter Relay 2 Ctrl
C355B-5
Sensor Gnd
C355A-10
AC Pressure Signal
C355B-6
Lambda Gnd Downstream
C355A-11
Acc Pedal Sig 2
C355B-7
TB Gnd
C355B-11
Starter Relay 1 Ctrl
C355B-8
Sensor Gnd
C355A-12
Manifold Pressure
C355B-10
Supply
C355A-13
Fuel Pump Ctrl
C355B-13
VRS+
C355A-15
Main Relay Ctrl
C355B-15
Coolant Temperature Sig
C355A-16
IGN Sw KL-
C355B-17
Reverse gear input
C355A-18
Clutch SW 10%
C355B-20
Throttle Pos Sig 2
C355A-19
Clutch 90% I/P
C355B-23
TB +ve supply
C355A-20
Eco Mode Sw I/P
C355B-30
Lambda Sig Upstream
C355A-21
Acc Pedal Sig 1
C355B-31
Camshaft sensor sig
C355A-22
Starter Relay F/B
C355B-33
Alternator DF Input
C355A-25
Sensor Supply
C355B-34
Heater Downstream
C355A-26
Acc Pedal Pot 2 Supp
C355B-35
Canister Purge Valve
C355B-27
Manifold Air Temperature
C355B-37
Knock Sensor Sig
C355A- 31
AC Compressor Ctrl
C355B-38
Knock Sensor Gnd
C355A-34
Crank Input KL-50
C355B-40
WT
C355A-35
Brake Sw (Lamps)
C355B-43
Fuel Injector 2
C355A-36
A/C Req Input
C355B-44
Fuel Injector 1
C355A-37
+ 5V Supply
C355B-45
Fuel Injector 3
C355A-38
Acc Pedal Pot 1 Supp
C355B-47
Chassis Gnd
C355A-41
Radiator Fan Ctrl
C355B-49
Lambda Gnd Upstream
C355A-46
AC Fan Control
C355B-50
Chassis Gnd
C355A-47
Brake Sw (ECU)
C355B-51
Throttle Valve +ve
C355A-53
Chassis Gnd
C355B-52
Throttle Valve -ve
C355A-54
Chassis Gnd
C355B-54
Ignition Coil 2
C355A-55
Battery Via Main Relay
C355B-55
Ignition Coil 3
C355A-56
Battery Via Main Relay
C355B-56
Ignition Coil 1
