ENGINE
155
0 1 ASSY CONNECTING ROD
AIRCOMPRESSOR
0 2 CONNECTINGRODBUSH
0 3 CON ROD BRG SHELL
HALF LOWERA/C
NORMAL
0 4 CON ROD SCREW.
0 5 HEX NUT (BALL PIN -
ROCKER ARM)
0 6 ASSY PISTONAIR
COMPRESSOR
0 7 SET PISTONRINGAIR
COMPRESSOR
0 8 PISTON PIN
10 CYLINDER SLEEVE
NORMAL
11 GASKETCYLINDER
SLEEVECYL BLOCK
12 HEXHEAD -COLLER BOLT
14 CYLINDER HEAD AIR
SUCTIONUNIT
15 SPRINGHOUSING
16 VALVEDISC
17 SUCTIONVALVE SEAT
18 SUCTIONVALVE CAP
19 VALVESPRING
20 PRESSUREVALVESEAT
21 GASKET
22 REDUCER
23 ASSYOIL LINE
24 SEALINGWASHER
25 PIPE UNION BOLT
SR.
DESCRIPTION
NO.
VACUUM PUMP
EXPLODED VIEWS
