SAFARI

486 PL ENGINE

Fig. 175

Fig. 173

Install oil separator on inlet manifold. Fig 172

Install oil separator hose and blow by pipes along

with support bracket on inlet manifold.

Fit oil filter with the help of spanner Pt. No. 2654 5890

1801 Fig. 173

Install power steering pump bracket along with pump

& pulley Fig 174

Install alternator with stay and tighten top and bottom

mounting bolts.

Place alternator belt over vibration damper pulley,

alternator pulley power steering pump pulley and

tensioner pulley as shown. Fig 175

Fig. 174

Fig. 172
