4 DLT ENGINE
Assemble other connecting rods with piston in same
manner.
C
heck end play of Con-rods. Refer Figure 126
Apply uniform liquid gasket "Anaerobic liquid gasket
TS 25408" (Code No. 5650 600 25 20).
F
it the ladder Frame.
Install oil pump drive chain over oil pump drive
sprocket gear on Crankshaft.
F
it oil sump assy. Tighten mounting bolts to specified
torque. Refer Figure 127
I
nstall crank shaft front oil seal using drift, 2654 5890
03 03. Refer Figure 128
F
it crank case front cover with NEW gasket.
T
ighten screw to specified torque. Refer Figure 129
Fig. 127
Fig. 128
Fig. 129
Fig. 126
