4 DLT ENGINE
I
nstall rear oil seal using drift, 2654 5890 03 04.
Refer Figure 119
L
ocate flywheel on crank shaft rear flange.
I
nstall locking plates and screw-in flywheel mounting
screws.
T
ighten flywheel mounting screws to specified torque.
Refer Fig. 120
L
ock them by bending lock plates. Refer Fig. 121
R
emove connecting rod bearing cap with shell.
I
nsert connecting rod in piston such that combustion
cavity on piston and bearing shell lugs on connecting
rod are on same side. Refer Figure 122
Fig. 120
Fig. 121
Fig. 122
Fig. 119
