TRANSFER CASE
33
TANSFER CASE
9. Position the front adapter assembly on the
case and place properly and tighten five bolts
of front adapter.
Apply 1.6 mm bead of sealant on the mounting
face for the transfer case.
B. FRONT OUTPUT SHAFT & YOKE
1. Insert the two new dowel pins.(If removed)
2. Press the ball bearing
(1)
using a drift
(Part
No. 2870 5890 26 04)
into the case and install
the snap ring
(2)
.
