880 / 1428
ENGINE COMPONENTS
12
Installation
:
1. Ensure that all the openings of the radiator
are closed properly except the inlet / outlet.
2. Install the radiator along with fan shroud/duct
on the vehicle ensuring proper alignment.
3. Connect the radiator fan wiring harness
connector.
4. Connect both inlet and outlet radiator hoses.
5. Tighten radiator bracket bolts as per the
specified torque. (9 Nm)
