FUEL SYSTEM
11
Remove RH-LH spring band clamp connected at
filter‘s inlet and outlet ports.
Carefully disconnect the pipe rubber hoses
connected at filter’s inlet & outlet ports.
Remove the LP filter mounting bracket and take-
out the filter.
Separate out the LP filter from its mounting
bracket.
REFITMENT OF L.P FILTER:
For fitment procedure, follow the reverse
procedure of “Removal”.
NOTE:
On filter,” IN” & “OUT” indications are provided
along with poka-yoke arrangement. Always
ensure to connect the pipelines to it’s respective
port only. Do NOT interchange
.
Conduct leak detection test after the fitment of
LP filter on vehicle.
