NANO

660

ELECTRICAL

3. Remove two screws securing roof mounted stop

lamp to the body and take out the lamp.

REFITMENT

1. Connect electrical connector.

2. Tighten two screws and fit stop lamp.

3. Tighten the screws and fit stop lamp housing.

BULB REPLACEMENT PROCEDURE FOR HIGH

MOUNTED STOP LAMP

1. Remove the plastic screws from the housing.

2. Remove the housing.

3. Rotate the bulb holder in anti-clockwise direction.

4. Replace the bulb.

5. Position the bulb holder back.

6. Place the cover in location

7. Press the plastic screws from the side of cover.
