TRANSAXLE

60

4. Remove the clutch release bearing.

5. Loosen the fork bolt.

6. Pull the yoke in the upward direction such as

the yoke is free from the lower bush.

7. Remove the shaft from fork and front half.

8. Remove the upper and lower bush.

NOTE:

Bush to be replaced if found worn out or

damaged.
