1001 / 1980
TRANSAXLE
57
2. OVERHAULING:
2.1 EXPLODED VIEW:
01
ASSEMBLY 160 DIA CLUTCH SET(NANO AMT)
02
ASSEMBLY 160 DIA. CLUTCH COVER AMT
03
ASSEMBLY 160 DIA CLUTCH DISC(UF75M LINING)
04
ASSY CLUTCH RELEASE BEARING
05
BUSH ON HOUSING
06
HEXA FLANGE.BOLT W/HEX.SOCKET
07
CLUTCH RELEASE SHAFT
08
CLUTCH RELEASED FORK
09
CLUTCH RELEASE LEVER
10
HEXA FLANGE BOLT M8X35
11
ASSEMBLY BACKCOVER WITH FOAM STRIP
12
HEXA FLANGE BOLT M6X30
13
HEXA FLANGE SCREW M6X14
14
SPRING WASHER
15
SET SCREW
