ENGINE 273 MPFI
•
Remove four hexagonal mounting bolts of intake
manifold mounted on engine head.
•
Disconnect both the injector electrical connectors.
•
Disconnect canister purge line between canister
purge valve and intake manifold.
•
Disconnect accelerator cable from throttle body.
•
Disconnect the fuel rail connection (Refer. Fuel
System)
•
Disconnect T-MAP sensor connector by pressing
the lock using screw driver & pull out the harness
connector.
•
Disconnect ISC valve connector.
