ENGINE 273 MPFI
191
ENGINE
OIL SUMP & OIL STRAINER
Oil Sump
Removal Procedure:
• Position the car on a two post lift.
• Drain the oil from oil sump. (Refer Engine Oil Drain
Procedure)
• Unscrew the hexagonal mounting bolts using ring
spanner.
• Take out the oil sump from engine block.
• Remove liquid gasket using scrapper.
• Clean the oil sump properly to remove any foreign
particles, if present.
• Check oil sump for leakage or damage. Replace it
if found damage.
Refitment Procedure:
• Apply
SEALANT LOCTITE 5910
black colour on
oil sump mating surface on block to ensure leak
proof joint.
• Tighten the hexagonal mounting bolts using ring
spanner at specified torque.
Inspection:
• Check for oil leakage when engine is started.
CAUTION
Risk:
Methyl Ethyl Ketoxime, which may cause eye
irritation and may cause sensation if in contact with
skin, if released during curing.
Safety:
Avoid contact with skin and eyes. Keep
out of reach of children.
First Aid:
In case of contact with eyes, rinse off
immediately with plenty of water and contact a doctor
or Poisonous Information Centre. If swallowed, do
not induce vomiting, contact a doctor or Poisonous
Information Centre immediately and show the
container or the lable. After contact with skin, wash
immediately with plenty of soap and water. If effect
persists, seek medical attention.
For best results, clean and dry all surfaces with a
residue free solvent.
Apply continous and even bead of silicone to one
surface surrounding all bolt holes.
Remove excess with knife at once. Assemble parts
immediately.
Do not squeeze out silicone by overtightening bolts.
Retorque will not be necessary.
Cures to touch in an hour and fully cures in 24 hours
measured at 21ºC and 50% relative humidity.
Allow more time in colder or dryer condition.
NOTE
