6. For vehicle having central locking unit :

(a) Disengage the link attached from latch to door

lock barrel.

(b) Disconnect electrical connector of central

locking master cum follower unit and take out latch

assembly.

follower unit and latch assembly by removing

mounting screws.

(b) Attached from outer handle to latch.

7. Remove the bolt of guide channel and take out

latch assembly.

8. Take out latch assembly along with central locking

master cum follower unit.

9. Disassemble central locking master cum follower

unit and latch assembly by removing mounting

screws.

5. Disengage following links :

(a) Attached from door inner handle to latch.
