For connector pin connection details refer below table

Also refer circuit schematic section for details

DIAGNOSIS INFORMATION& PROCEDURE

CONDITION

POSSIBLE CAUSE

CORRECTION/REFERENCE ITEM

One or more of the window 1. Fuse (30A) for the respective

Replace the fuse

winders not working

door loose/ blown under driver

seat

2. 2 pin Window Winding motor

Fit the connector properly

Connector loose

3. 6 pole WWS Console switch

Fit the connector properly

connector loose

Window winders moving 1. Battery discharged

Recharge the battery

2. WMS Console master switch Fit the connector properly

16 pole connector loose

slowly/not working at all
