NANO

578

STEERING SYSTEM

STEERING RACK AND PINION ASSEMBLY

Removal

1. Loosen upper universal joint bolt. (Do not remove

the bolt)

2. Remove lower universal joint bolt and make

steering rack free from the steering column

assembly.

3. Remove both front wheels (Refer wheel removal

procedure/Wheels and tyres group)

4. Remove tie rod ball joint nyloc nut.

5. Remove tie rod end by using tie rod ball joint puller.

(Part No. 265458903304)

NOTE:

Steering arm should not be hammered for removal of

tie rod outer ball joints as this may lead to damage of

steering arm part.
