NANO

DRIVETRAIN

403

DRIVETRAIN

GEAR SHIFTER LINKAGE

A. GEARSHIFTERCABLEREPLACEMENT

1. Remove the Gear shifter console, for procedure

refer Body group GEAR CONSOLE REMOVAL

ANDFITMENT.

2. Disconnect the shifter cable at the gear lever end

by removing the metal clip by expanding it and

pulling it out.

3. Disconnect the selector cable by removing the lock

pin with the help of screw driver. (Do not reuse the

lock pin).

4. Pull out the mounting clips and free the cable from

the gear shifter housing using a screw driver.

5. Disconnect the cables at the transaxle end as

follows.

6. Press the clips to disengage the snap and pull out

the cable.
