DRIVETRAIN
18. Insert the collar washer in the bell crank housing
in the top cover.
14. Place the detent on the interlock piece and spring.
15. Place the shifter selection finger on the inter lock
piece such that the interlocking notches mesh
with the detent.
16. Press the finger towards the detent and insert
the whole assembly into the selector shaft such
that the interlock piece barrel is right below the
filler cum breather.
17. Fit the dowel (spiral) pin into the slot in the finger
to lock it with the shifter shaft and fit the circlip.
13. Place the barrel along with the spring in the inter-
lock piece.
