NANO

168

ENGINE 273 MPFI

SYSTEM MAINTENANCE

Radiator Pressure Cap

• Remove radiator cap as per procedure given below.

CAUTION

Removing the radiator cap while the engine is hot

can cause the coolant to spray out, seriously scald-

ing . Always let the engine and radiator cool down

before removing the radiator cap.

• Turn the radiator cap anticlockwise, without press-

ing down on it, until it stops. This relieves any pres-

sure remaining in the cooling system.

• Press and turn the radiator cap anticlockwise

further to remove it.

• Check the coolant level. The coolant level should

be up to the base of filler neck. Add coolant if it is

low.

• Put the radiator cap back on. Tighten it fully.

• Pour coolant into the auxiliary tank . Fill it to half-

way between the MAX and MIN marks. Put the

cap back on the auxiliary tank.

Inspection

• Replace the pressure cap with new one if leakage

is observed even after cleaning the filler neck.

• Check radiator cap for perfect sealing in filler neck.

• Check radiator cap, main and vacuum valve open-

ing pressures.

• Replace defective cap with new one of recom-

mended rating.

Test for main valve opening

Radiator cap main valve should not open below the

specified pressure value.

On the vehicle, the functioning of radiator cap main

valve can be checked by observing increase in cool-

ant level in auxiliary tank at high coolant temperature.

Test for vacuum valve opening

On the vehicle, the functioning of the radiator cap

vacuum valve can be checked by observing decrease

in coolant level in an auxiliary tank when it cools down

compared to higher level at high temperature .

Confirmation of Proper Sealing

• After the sealing work is over, assemble the radia-

tor properly.

• Subject the assembled radiator to leakage test as

per said procedure.

CAUTION

If the problem of leakage persists, it is advisable

to replace the radiator with new one

Coolant Level

•

If the coolant level in the auxiliary tank is at or

below the MIN line, add coolant to bring it up to the

MAX line.

•

Inspect the cooling system for leaks.

•

Coolant should always be a mixture of Antifreeze

Agent (Ethylene Glycol) + Soft Water {Ratio 50 :

50}

•

Never add straight antifreeze or plain water.

•

Always use genuine recommendedAntifreeze.

The cooling system contains many aluminum com-

ponents that can corrode if improper antifreeze is

used.

•

Some antifreeze, even though labeled as safe for

aluminum parts, may not provide adequate protec-

tion.

•

If the auxiliary tank is completely empty. Check

the coolant level in radiator.

CAUTION

Allow the coolant in the radiator to reach to the room

temperature.

NOTE

If auxiliary tank is found completely empty, top up

coolant through radiator as well as auxiliary tank

cap..
