SAFARI STORME

STEERING

A. STEERING RESERVOIR

REMOVAL

1. Drain the power steering oil.

(For procedure refer

oil replacement procedure in this section.)

2. Loosen and remove the mounting bolt and take

out the sleeve/spacer, then remove mounting

bolts of the bracket holding the reservoir with

the BIW.

3. Remove the spring band clamp and disconnect

the suction line and the return line from the res-

ervoir end.

4. Take out the reservoir assembly.

NOTE

Plug holes of both reservoir and lines to avoid en-

trance of dirt and contamination.

FITMENT

For fitment follow reverse procedure of removal.

B. POWER STEERING PUMP

REMOVAL

1. Drain the power steering oil.

(For procedure refer

power steering oil replacement in this section.)

2. Remove power steering pump belt.

(For proce-

dure refer Alternator Belt removal in Engine

section.)

3. Disconnect the hoses from the power steering

pump.

4. Lock the power steering pump pulley, using a

screw driver and loosen the pulley mounting

bolts.

5. Remove pulley mounting bolts (1) along with

spring washer (3 Nos.) and remove the pulley

(2).
