SAFARI STORME

STEERING

5. Remove steering wheel using steering wheel

puller. (Part No. 2779 5890 46 01)

CAUTION

Care should be taken such that self-

cancellation lugs do not get damaged (self-

cancellation lugs are shown in below figure with ar-

rows).

INSPECTION:

Check for any damage to self-cancellation

lugs, if found, replace complete steering wheel

INSTALLATION:

6. Align the marks made on the steering wheel

and the shaft. Install steering wheel on steering

shaft.

7. Tighten the steering wheel nut to the specified

torque.

8. Tightening torque (Steering wheel nut) = 4Kgm

9. Fit horn pad (Press fit type).

10. Connect battery.
