BRAKES
55
BRAKES
7. Keep the wooden piece in between the plunger
and the caliper housing and blow dry
compressed air into the caliper gradually
through the inlet port
(Where banjo bolt is
connected).
Now you will observe the piston
coming out of the caliper gradually.
8. Remove the piston from the caliper housing.
9. Remove the piston boot from the caliper
housing.
10.Follow the same procedure for the other piston
also.
11.Remove the sealing rings from the grooves in
the caliper housing one after the other.
12.Remove the bleed screw from the caliper
housing.
