ENGINE
153
ENGINE INSPECTION SHEET
CYLINDER BLOCK AND PISTONS
SHEET 2
Engine No. ………………………………………
Chassis No. …………………………………….
Kilometers ………………………………….......
Kilometers since last overhaul …………………
Reason for dismantling …………………………………..
………………………………………………………………
………………………………………………………………
………………………………………………………………
WITHOUT BEARING SHELL WITH BEARING SHELL
Measuring with bearing shells: Dial gauge set at ......mm
Measuring
Direction
CRANK SHAFT BEARING NO.
1
2
3
4
5
A (mm)
B (mm)
C (mm)
OVALITY (mm)
Measuring without bearing shells: Dial gauge set at ......mm
Measuring
Direction
PARENT BORE NO.
1
2
3
4
5
A (mm)
B (mm)
C (mm)
OVALITY (mm)
Conclusions/Recommendations
Checked by …………………..Date …………
