9.2.29 “B” PILLAR TRIMS
REMOVAL
1.
Remove front row seat belt lower mounting
(refer seat belt removal procedure in this
section).
2. Pull out the “B” pillar lower trim.
NOTE
While pulling “B” pillar lower trim, care should be
taken such that tree clip don’t get damage. Refer
locations of tree clips given below:
3. Remove front row seat belt upper mounting
(Refer seat belt removal procedure in this
section)
4. Pull out the upper trim outward and separate it
from the vehicle
NOTE
While pulling “B” pillar upper trim, care should be
taken such that tree clips don’t get damaged Refer
locations of tree clips given below:
FITMENT
For fitment follow the reverse procedure of
removal.
