1412 / 1575
BODY
17
BODY
9.2.3.B-CONSTRUCTIONAL DETAILS OF DASHBOARD
SR.
NO.
DESCRIPTION
01
Dash board pre assembly RHD
02
Top utility assembly
03
Side window demister grille LH
04
Side window demister grille RH
05
Side air vent assembly LH
06
Side air vent assembly RH
07
Deco finisher assembly LH Side
08
Deco finisher assembly RH Side
09
Radio case
10
Dash board lower center utility box
11
Air duct side LH
12
Air duct side RH
13
3.5X16 flange screw
14
4.8X17 flange screw
15
3.5 C-nut
16
Glove box support bracket RHD
17
Washer A6.4
