BODY
14
11. Trunk Lid Sill Cover :
Removal :
1. Remove the trunk lid primary seal, just
enough to remove the sill cover.
2. Remove the assembly luggage compartment
carpet, for easy removal of trunklid sill cover.
3. Remove plastic rivet clip at fine location
starting from outboards fixations towards
inboards fixations, in manner.
4. Gently pull out the trim to remove the 4 tower
metal clips, starting with outboards tower clips
and then middle two metal clip tower and
symmetric mountings.
5. Remove the trunk sill trim away from body
along mounting direction as there are two
locators.
Re-Fitment :
Carry out the removal process in reverse
order in appropriate sequence for re-fitment of
trunk lid sill cover.
