SUSPENSION
3
6.2 SPECIAL TOOLS
6.2.1 FRONT SUSPENSION:
SR. NO.
DESCRIPTION
PART NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10
11.
12.
13.
14.
15.
16
17.
18.
19.
20
21
22
23
Reset pad removing inner race of bearing from hub
Holder for hub assembly
Puller for pulling out the front hub
Clamp for removing inner race for hub
Striker for pulling out the hub
Drift for installing the bearing in knuckle
Drift for fitting knuckle assembly on hub
Puller for removing ball joint
Spring compression tool
Puller for removing inner race from hub
Puller for knuckle bearing
Handle for drift
Drift for Lower arm Front Pivot Bush
Installer for Lower arm Front Pivot Bush
Remover for Lower arm Front Pivot Bush
Drift for Lower arm rear Pivot Bush
Installer for Lower arm rear Pivot Bush
Remover for Lower arm rear Pivot Bush
Stand for holding lower link
Support-Ball joint removal & fitment
Puller for removing ball join
Drift-Ball joint fitment
Drift-Ball joint removal
2702 5890 2612
2702 5890 3301
2702 5890 3302
2779 5890 3303
2702 5890 3304
2779 5890 3301
2576 5890 4401
2871 5890 4601
2702 5890 3202
2654 5890 3508
2779 5890 3302
2640 5890 3511
2871 5890 3204
2871 5890 3205
2871 5890 3206
2871 5890 3201
2871 5890 3202
2871 5890 3203
2871 5890 3209
5427 5890 3201
2871 5890 4601
2779 5890 3501
2834 5890 2614
6.2.2 REAR SUSPENSION
SR. NO.
DESCRIPTION
PART NO.
1.
2.
3.
Kit Twist beam pivot bush removal and installation
Rear hub unitized bearing installer
Rear hub unitized bearing remover
2871 5890 3212
2871 5890 4201
2871 5890 4202
