6.1.2 TIGHTENING TORQUES FOR SUSPENSION
SR. NO.
DESCRIPTION
TORQUE VALUE (Kg-m)
FRONT SUSPENSION
1.
Front strut mounting on Knuckle
8-10
2.
Strut top mounting
6-7
3.
Strut tower mounting
2.3
4.
Driveshaft lock nut
23-26
5.
Sub frame mounting bolts(at 4 corners)
18
6.
Sub frame mounting bolts(at center)
3
7.
Lower link to sub frame mounting
16
8.
Stab link mounting on strut
5.5
9.
Stab link on anti roll bar
5.5
10
Lower arm to knuckle
5.5
11
Anti roll bar link mounting on Sub-frame
4.5
REAR SUSPENSION
1
Torsion beam bracket mounting on body
10
2
Torsion beam to shock absorber
6
3
Pivot bush cross bolt
10
4
Rear Shock absorber mounting bolts to body
2.5 to 3
5
Back plate bolts
4.5
6
Stake nut in brake drum assembly
17.5 ± 2
