SUSPENSION
1
6.1 TECHNICAL SPECIFICATIONS AND TIGHTENING TORQUES
6.1.1 SPECIFICATIONS
:
(A) Front Suspension
Type:
Independent, lower wishbone, McPherson strut type with anti roll bar at front.
(B) Rear Suspension
Type:
Semi Independent, twist beam with coil spring and shock absorbers.
(C) Wheels and Tyres
Tyres:
175/65 R14 82T Tubeless tyre and 175/65 R15 84T
Tyre geometry:
A tyre of size 175/65 R14 82T is made up of following information:
175 - Tyre section width in millimeters
65 - Aspect ratio in % (the height of the side wall divided by the tyre’s width)
R - Tyre’s construction type - in this case it’s a radial type
14 - Rim diameter in inches
82T - Service description (Load Index + Speed Symbol)
Tyre pressure:
Front: 33 to 35 psi
Rear: 28 to 32 psi
Wheel Rims:
5J X 14” steel rims and 5.5J x 15''
(D) Steering geometry (In unladen condition)
Front axle
Rear axle
Toe - in (mm)
Not applicable
Toe - out (mm)
0 -13'
Camber angle
30' ± 30'
12' ± 15' (Fixed)
Caster angle
3.1°± 45'
Not applicable
King pin angle
11.90
Not applicable
Not applicable
Not applicable
