5.7. O. ASSEMBLY OF TOP COVER:
1. DISMANTLING:
1. Loosen the M12 Nut and remove the bell
crank lever assembly along with bellow and
bush, spacer & sealing ring as shown below
figures.
2. Loosen the cross pin bolt of selector shifter
shaft to remove the interlock piece along with
barrel spring, Central Detent and finger
(selection and shifting).
3. Loosen the M8 bolts to remove the Top cover
plate, Cup, Spacer and springsfrom the top
cover as shown in below figures.
