DRIVETRAIN-TA65 Star
52
3. 1st / 2nd SYNCHROPACK ASSEMBLY:
1. Place inner cone.
2. Place the intermediate cone in such a way
that the lugs sit exactly in the slots of 1st gear
3. Now place the outer synchro cone.
4. Place the engaging gear in such a way that
the inner cone lugs sit properly inside the
grooves provided in the engaging gear.
5. Place the engaging gear 1st and 2
nd
such that
the reverse gear tooth over it is towards the
1st gear.
6. Place the 2
nd
gear and assemble the twin
cones as shown and place it over the
engaging gear as shown in below figures.
