92 / 745
KRYOTEC ENGINE
84
23. Remove the exhaust pipe support bracket bolt
(1).
24. Remove the exhaust flange nuts (2).
25. Disconnect the exhaust pipe from the Diesel
Particulate Filter (DPF) and remove the flange
gasket.
26. Remove the rear engine mount isolator to front
crossmember bolt (1).
27. Remove the bolts (2) and (3) and the rear
engine mount isolator bracket.
28. Remove the rear engine mount isolator.
29. Remove the left and right half shafts (Refer to
03 - Differential and Driveline/Half Shaft/Removal
and Installation).
30. Unscrew the cap for brake/clutch fluid reservoir
and install the 2000001400 Cap Depression brake
system/clutch (1).
31. Disconnect the reverse lamp switch wire
harness connector (1).
32. Remove the bolt (2) and reposition the battery
ground cable.
33. Disconnect the coolant hose quick couplings
(1).
