BODY

51

1.4.41 FRONT WHEEL ARCH LINER

REMOVAL

1. Remove clip push button of front cladding,

fender.

2. Pull out the cladding fender.

3. Remove mounting screw located inside the

arch liner.

4. Remove four Push on Nuts.

5. Remove front wheel arch liner.

FITMENT

For fitment follow reverse procedure of removal.
