Disconnect the cable from inner lock handle
connecting inner handle to latch assembly power
front.
7. Remove door inner lock handle.
FITMENT
For fitment follow the reverse procedure of
removal.
1. Insert screw cap to tuck in the vertical edge.
2. Press the screw cap.
1.4.12 FRONT OUTER DOOR LOCK
REMOVAL
1. Remove the door trim. (For procedure refer
front door trim removal process.)
2. Remove the plug.
3. Remove the mounting screw of front door lock.
4. Remove the lock barrel.
