475 / 801
BODY
31
6. Disconnect the inner handle cable from the
door inner lock handle.
7. Loosen and remove three door latch mounting
screw.
8. Disconnect outer handle link from the handle
end.
9. Remove the latch.
FITMENT
For fitment follow reverse procedure of removal.
4.18. TAIL GATE
REMOVAL
1. Open the tail gate.
2. Pull out Access cover tail lamp located inside
the “C” pillar trim
3. Disconnect the tail gate all wiring harness
located inside the “C” pillar trim and pull out the
wiring harness from outside.
