FATC
38
iii. CLOSED DOOR TEST
TEST DURATION: 10 min.
INITIAL VEHICLE CONDITIONS
Run the vehicle in the above condition with all doors closed for 10 min. At the end of 10 min insert the probe at
the front vent and record the readings similarly insert the probe at the rear vent and record the reading.
RH: Relative Humidity.
NOTE
•
The above table is applicable if the ambient RH is 40%.
•
The tables are applicable ambient temperature varying from <30 °C to >40 °C.
