LV ELECTRICAL SYSTEM
48
A. REMOVAL LEVEL A
1. Carefully pry out Lower Display cover.
2. Take out cap Display.
3. Remove 4 mounting screws on Infotainment
head unit.
4. Disconnect all the electrical connections to
take out the display.
5. Pull out Center Fascia Assembly.
6. Disconnect all the electrical connections to
the control panel.
7. Remove the mounting screw and take out
the panel.
