ELECTRICAL
98
TELL TALES COLOR INDICATOR
REMARKS
vehicle speed goes above 15 km/ hr, Then Co-Driver
(Passenger) Seat belt telltale will also start flashing along with
audio alarm during Final Warning.
Note:
Buckle the Co-Driver (Passenger) seat belt to stop
Audible warning and telltale OFF.
Immobilizer
Warning
Indicator
Red
(High
End –
Amber)
This symbol is of a system that disables engine starting if User
do not use the original key. The user has to use original key
for authentication and unlocking the car. Refer to Immobilizer
section for details.
Lamp Blink: Car is in immobilized condition when key is not
inserted.
Lamp OFF: Normal condition (Authenticated user) and engine
shall start.
Lamp ON: Problem with key/system. Get the problem
attended to at TATA authorized Service center.
Check
Engine Lamp
Amber
This is symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after the engine starts.
Caution:
This symbol will remain ‘ON’ for any engine related fault that
may cause damage to engine. Get the problem attended to at
TATA authorized Service center.
Speed Limit
Lamp
Amber
This symbol comes ON with one time audible sound per 2
minutes when vehicle speed is more than 80Kmph.
This symbol remains ON with continuous audible sound when
Vehicle Speed is more than 120 kmph. At this stage, reduce
the vehicle speed.
This symbol and audible sound will get OFF when vehicle
speed reduces below 80 kmph.
Diesel
Particulate
Filter Lamp
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and goes
‘OFF’ after the engine starts.
This symbol comes ON when Diesel Particulate filter in
exhaust system is malfunctioning.
Get the problem attended to at TATA authorized Service
center.
NOTE:
This telltale is applicable only for Diesel engine
EPAS Lamp
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and goes
‘OFF’ after 4 seconds.
This symbol comes ON when there is malfunction in Electronic
Power Assisted Steering.
Get the problem attended to at TATA authorized Service
center.
