924 / 1006
ELECTRICAL
97
TELL TALES COLOR INDICATOR
REMARKS
Low
Fuel
Indicator
Amber
This symbol lights up when ignition is turned ‘ON’. The symbol
lights up continuously if fuel level in the tank is low. Fuel needs
to be filled immediately.
It will blink if there is any fault in the system. Take vehicle to
the Tata Motors authorized service station if the symbol starts
blinking.
High Coolant
Temperature
warning
Red
This symbol lights up when the ignition is turned ‘ON’ and
goes ‘OFF’ in approx. 4 seconds.
If the engine is overheating, this indicator blinks along with an
audible buzzer.
At this stage, take the car to the nearest authorized Service
outlet. This symbol blinks and audible buzzer sounds
simultaneously when engine coolant temperature is more than
normal.
When engine coolant temp increases to hazardous level,
telltale will blink with RED color and it is accompanied by
audio warning.
Warning:
Never remove the radiator pressure cap from the radiator
when the engine is hot. Do not restart the engine until the
problem has been duly attended.
Water in fuel
Indicator
Amber
This symbol indicates excess water
accumulation in the
sedimenter. It turn ‘ON’ when ignition is switched ‘ON’ and
shall go ‘OFF’ in approx. 4 seconds. When this lamp remains
‘ON’, water needs to be drained from sedimenter immediately.
This symbol also turns ON when Fuel Filter Clogging warning
is activated (if applicable).
NOTE:
This telltale is applicable only for Diesel engine
ABS Indicator
Amber
When ignition is turned ‘ON’, this symbol comes ‘ON’ for three
seconds and goes ‘OFF’.
This symbol continue to remain 'ON' after Ignition ON if there
is a problem in the ABS system. Get the problem attended to
at TATA authorized Service center.
Airbag
Indicator
Red
The air bag warning symbol comes on for approximately 4
seconds when the ignition is turned ‘ON’ and goes ‘OFF’.
Warning:
If it remains ‘ON’ or blinks, Get the problem attended to at
TATA authorized Service center.
Driver Seat
belt Indicator
Red
If Driver seat belt is not buckled and IGN is ON then Telltale
will be ON as initial warning with No audio chime.
If Driver seat belt remains unbuckled and vehicle speed goes
above 15 km/ hr, driver Seat belt telltale will also start flashing
along with audio alarm during Final Warning.
Note:
Buckle the Driver seat belt to stop Audible warning and
telltale OFF.
Co-Driver
Seat
belt
Indicator
(passenger)
Red
If Co-Driver (Passenger) is present and its seat belt is not
buckled and IGN is ON then Telltale will be ON as initial
warning with No audio chime.
If Co-Driver (Passenger) seat belt remains unbuckled and
