815 / 1006
BODY
5
1. WIND DEFLECTOR
REMOVAL
1. Position the Glass panel in the open position.
2. Use flat blade screwdriver to pry open spring
holder (black plastic part) on both the sides.
FITMENT
For fitment follow the removal procedure in
reverse.
NOTE
Observe the spring holder orientation before
removal; label and mark if necessary.
2. GLASS PANEL
REMOVAL
1. Position the Glass panel in the Close position.
2. Pull and remove the flex covers on both the
sides.
3. Remove the Four (4) M5 Screws both the sides
on the glass panel bracket using T25 Torx driver.
4. Remove Glass panel from the vehicle.
