BODY
1
ON VEHICLE PROCEDURE
A. FRONT BUMPER REMOVAL (NEXON BS
VI)
1. Open the bonnet.
2. Remove clips M6 on Front Bumper.
3. Remove ST 4.8X16 Screws on Front Bumper
from LH and RH sides.
4. Remove Flange Screw M6X20 and ST
4.8X16 from bottom side of Bumper.
5. Disconnnect
Fog
Lamp
Electrical
Connection.from LH and RH Sides.
6. Take out Front Bumper assembly from
Vehicle.
FRONT BUMPER ASSEMBLY
Follow the reverse procedure of Front Bumper
Removal.
