HVAC
48
3. Pull out end cover LH side.
4. Remove one mounting screws & Pull out dash-
board mid panel.
5. Remove six mounting screws of glove box.
6. Remove four mounting screws of glove box from
bottom side.
7. Open the glove box and pull out AC adaptor top
Utility Bin.
8. Remove one mounting screws of glove box,
which is inside of glove box.
