DRIVESHAFT MT
10
6. ON VEHICLE PROCEDURE
A. DRIVE SHAFT (LH / RH) REMOVAL
(PETORL VEHICLE)
1. Position the vehicle properly on the two-post
lift.
2. Lift the vehicle on using two-post lift and
remove the front wheels LH & RH.
3. Drain the Transaxle oil through Drain Plug.
4. Remove earthing cable from gear box.
5. Remove stub axle ball joint Mounting &
Loosen Lower Control Arm on LH & RH side.
6. Remove driveshaft lock nut LH& RH.
7. Remove ball joint (steering rack) from steering
knuckle from both sides.
8. Remove vertical link mountings on
suspension rod for both RH & LH sides.
