1.5L REVOTORQ BS VI ENGINE
132
22. Fit LH and RH engine mounting bracket to
engine.
SPECIAL TOOL
RH Mounting Bracket -:
5438 5890 2401
SPECIAL TOOL
LH Mounting Bracket -:
5424 5890 2403
23. Mount the engine on overhauling stand.
ii. REMOVAL OF INTAKE MANIFOLD
1. Remove the electronic throttle valve.
2. Remove the EGR pipe.
3. Remove the EVRV to EGR cooler hose.
